Oracle Label Security Licensing

Oracle Label Security Licensing for On-Premise and Cloud Deployments

Oracle Label Security (OLS) is an advanced Oracle Database option that provides row-level data protection by assigning classification labels to data.

However, Oracle Label Security licensing is not included with standard Oracle Database licenses; it requires a separate license for Enterprise Edition deployments.

This advisory provides IT asset management professionals with a clear overview of OLS licensing, including its cost structure, usage considerations, and best practices to avoid compliance pitfalls in global enterprises.

Introduction to Oracle Label Security

Oracle Label Security is a security feature of Oracle Database Enterprise Edition that enforces multi-level access control within the database.

It enables organizations to assign a classification label (such as Public, Confidential, Secret, etc.) to each row of data and restrict access to data based on a user’s clearance level. In practice, this means users only see the data they are authorized to see, even when querying the same table as others.

This powerful capability is especially valuable in industries like government, defense, and finance, where strict internal data segregation is required.

Because OLS builds on Oracle’s built-in Virtual Private Database (VPD) technology, it provides a ready-made framework for implementing label-based security policies without requiring custom coding.

For enterprises that need granular data security, OLS can be a crucial tool – but it comes at an additional licensing cost.

Use Cases and Importance for Enterprises

Implementing Oracle Label Security is a sensible choice for enterprises that handle sensitive or regulated data that must be compartmentalized. For example, a multinational bank might use OLS to ensure that regional data managers can only view customer records for their region.

Similarly, a government agency could label data as Unclassified, Confidential, or Top Secret and ensure that personnel only access data appropriate to their clearance level. These use cases demonstrate OLS’s ability to simplify compliance with data privacy laws and internal security policies by enforcing controls at the database level.

However, not all organizations require such fine-grained controls. Many enterprises meet their needs with standard database security and application-level controls.

ITAM professionals should carefully evaluate if the benefits of OLS outweigh the costs, since enabling OLS triggers the requirement for a separate license.

In cases where similar outcomes can be achieved with built-in features (like Oracle VPD or application logic), OLS may be avoidable, saving on licensing fees.

On the other hand, when mandated by regulations or when data sensitivity is extremely high, OLS provides a robust, centrally-managed security mechanism that justifies its use (and cost) in an enterprise environment.

Licensing Basics and Cost Structure

Oracle Label Security is licensed as a separate optional product for Oracle Database Enterprise Edition. It is not included in the base Enterprise Edition license on-premises; you must explicitly license OLS if you use it.

Key points of the licensing structure include:

• License Metrics: OLS can be licensed either by Processor or by Named User Plus (NUP), mirroring the database’s license metric. In other words, if your database is licensed per processor, you must license OLS for each processor of that database server. If your database is licensed per user, you need to purchase the equivalent number of NUP licenses for OLS (with Oracle’s standard user minimums, typically 25 NUP per processor as a floor for Enterprise Edition). This alignment ensures the OLS coverage matches the database usage.
• Cost: Oracle’s list price for Label Security is roughly in line with other database options. According to recent price lists, OLS is ~$11,500 per processor (full upfront license, plus annual support at ~22% of the license cost). For Named User Plus, the cost is typically proportional (Oracle often sets NUP pricing at a fraction of the processor price, e.g., roughly $230 per named user for OLS, given the usual 50 NUP = 1 processor ratio for options). Enterprise discounts or agreements can reduce these prices, but OLS remains a significant investment, especially for servers with many cores.
• Included vs. Extra Cost: While on-premises Enterprise Edition always treats OLS as an extra-cost option, there are scenarios where OLS is included by default:
  • Oracle Database Personal Edition and Oracle Database Free (Express Edition): OLS is included at no extra charge in these editions. These are typically used for single-user or development environments, rather than large enterprises; however, this means that testing OLS in a free edition is possible without a license fee.
  • Oracle Cloud Subscription Tiers: In Oracle’s cloud, if you use the “Enterprise Edition – High Performance” or “Enterprise Edition – Extreme Performance” database services (or Exadata Cloud Service), Oracle Label Security is included in the bundled features. These higher-tier services come at a premium cost but allow unlimited use of options such as OLS and Database Vault. In contrast, the lower-tier “Enterprise Edition” service (sometimes called EE BYOL or standard edition in cloud) does not include OLS by default – you would need to bring your own OLS license or upgrade the service tier.
  • Engineered Systems: If running databases on engineered systems like Oracle Database Appliance or Exadata on-premises, OLS is still a paid option (since those use Enterprise Edition licenses). However, if you have an Exadata Cloud@Customer or Exadata Cloud Service subscription, OLS is included as part of that service’s feature bundle.

The table below summarizes where Oracle Label Security requires a separate license and where it’s included:

As shown, Oracle Label Security licensing is typically an additional cost for traditional on-premises deployments, whereas certain Oracle cloud offerings include it. Enterprises must account for these differences when planning budgets or migrating workloads.

On-Premises vs. Cloud Considerations

The decision of where to run Oracle workloads has a direct impact on OLS licensing strategy:

• On-Premises Deployments: Every Oracle database server that uses OLS must be fully licensed for it. This means if you enable OLS on a production database, you’ll pay for each processor on that server. If that database runs on a multi-node cluster (RAC), each node’s processors must be licensed. Likewise, any standby databases or disaster recovery instances that are open for use with OLS-protected data should also be licensed (if they are only used in failover and not open for read, they may not need the option license until a failover event, but enterprises often license both primary and DR to be safe). On-premises, OLS is often purchased alongside Database Vault and Advanced Security as part of a security toolkit; however, each is a separate option license. Importantly, Oracle’s license rules specify that if OLS is used in any capacity on a database, the entire database instance must be licensed for it. You cannot enable it for just one schema or a subset of users without licensing the whole database environment. In a multitenant (pluggable database) architecture, if any PDB in a container uses OLS, the option must be licensed at the container (CDB) level for all its processors.
• Cloud Deployments: Oracle has incentivized cloud adoption by bundling many options into certain service tiers. Suppose an enterprise opts for Oracle’s Database Cloud with High Performance or Extreme Performance edition. In that case, you essentially obtain the rights to use OLS (and other options, such as Database Vault and Partitioning) without a separate purchase. This can simplify cost management – the hourly or monthly rate of that service covers everything. However, if you choose a lower-cost cloud service (or bring your license model), you must ensure you have OLS licenses or upgrade the service if you want to use OLS features. One advantage of cloud inclusion is cost predictability: you don’t need to count cores and buy perpetual licenses; instead, you pay a known subscription fee. On the flip side, if your organization already owns on-prem OLS licenses (perhaps via a ULA or previous investment), a BYOL cloud deployment might let you leverage those licenses on cloud VMs. Always map out what you already own versus what the cloud service provides. Additionally, note that Oracle Autonomous Database services include certain security features by default (for example, Database Vault is enabled in Autonomous Data Warehouse for compliance); however, the custom use of Oracle Label Security on Autonomous Database may not be available or may require specific Oracle involvement. Always confirm the latest cloud service guide to see if OLS can be utilized in autonomous or managed services.

In summary, cloud can effectively “include” Oracle Label Security licensing in the subscription cost if you choose the right service level. In contrast, with on-premises solutions, you need to budget for it as a separate line item.

Enterprises with hybrid environments should avoid double payment. If you move a workload to the cloud, consider reassigning or terminating unused on-premises licenses (in line with contract terms) to optimize costs.

Common Pitfalls and Compliance Risks

Licensing Oracle Label Security can be tricky. Many enterprises have fallen into one of these common traps:

• Accidental Usage: Oracle Database software often includes the OLS binaries and even schemas (like the LBACSYS user) installed by default or when certain configurations are enabled. A DBA or developer can create a label security policy on a table (for testing or a small use case) without formal approval. Even if used only briefly, this technically requires a license. Oracle License Management Services (LMS) scripts will detect OLS policies or related objects during an audit. Unlicensed usage – even inadvertently enabling OLS on a single table – can result in non-compliance findings. Actionable takeaway: regularly scan your databases for any label security configurations (policies, labels, OLS-specific user accounts) to catch unintentional use.
• Assuming Database Vault Covers OLS: Oracle Database Vault, another security option, automatically activates OLS under the hood (because DB Vault uses label concepts for its internal mechanisms). However, a Database Vault license does not give you free rein to use Oracle Label Security for your labeling policies. Oracle’s rules explicitly state that if you want to create your own label security policies, you need a full OLS license – the OLS that comes with Database Vault is restricted for Vault’s use only. A pitfall is when companies license Database Vault (for its intended purpose) and then think they can also label data with OLS. This is non-compliant. The safe approach is to treat OLS and DB Vault as separate options, each needing licensing if deployed (though they complement each other well for defense-in-depth).
• Multitenant and Partial Deployment: As mentioned, in a multitenant database, you cannot license OLS for just one pluggable database. If any PDB uses it, all the host’s processors need to be licensed. Enterprises sometimes split workloads into separate PDBs, thinking they will enable options like OLS only in one PDB to save cost – this doesn’t work under Oracle’s licensing policy. The same logic applies to Real Application Clusters: if OLS is active on a clustered database, all nodes must be licensed, even if only one instance actively uses the feature. Licensing is tied to the installed/available feature, not just actual usage at a given moment.
• Cost Underestimation: Label Security’s cost can add up quickly, especially on modern multi-core servers or large clusters. A compliance risk arises when budgets account for base database licenses but overlook options. At audit time, the organization may face a substantial true-up bill for OLS. Avoid this by always reviewing which Oracle features are in use (or even just enabled) and cross-check if they require separate licenses. Oracle provides a Database Feature Usage Statistics view and audit scripts that highlight the usage of options. IT asset managers should proactively utilize these tools internally.
• Ignoring Support Renewals: If you purchase Oracle Label Security licenses, remember that annual support fees (typically ~22% of the net license cost) are required to stay in compliance and receive updates. Dropping support can lead to inadvertent non-compliance if you upgrade database versions or need patches (since using an option on an unsupported license could violate terms). Always include the ongoing support cost in the total cost of ownership for OLS.

In essence, diligent governance is key: track where OLS is deployed, ensure it’s licensed wherever used, and educate technical teams about the implications of enabling such features.

A good practice is to maintain an internal policy that DBAs must request approval from the license management team before enabling any extra-cost database options, such as Label Security.

Cost Management and Optimization Strategies

For organizations that determine Oracle Label Security is necessary, there are ways to optimize its licensing impact:

• Consolidate Usage: Since licensing is often per processor, running all workloads that need OLS on a dedicated server or cluster can contain the scope. Rather than enabling OLS on many databases enterprise-wide, consider centralizing the sensitive data that truly requires labeling onto fewer databases. This way, you license a smaller number of servers for OLS. For example, instead of 10 databases each partially using OLS, consider architecting a secure data hub (with OLS) and allowing other apps to access data via views or services. Fewer licensed environments = lower costs.
• Leverage Oracle Agreements: Enterprises negotiating an Oracle Unlimited License Agreement (ULA) or a cloud consumption agreement should evaluate including Oracle Label Security. If OLS is part of a ULA contract, you can deploy it widely during the ULA term without counting licenses (just ensure you properly certify usage at the end). If it’s not included, either avoid using OLS or consider amending the agreement. Oracle sales often bundle OLS with other security options at a discounted rate if it’s part of a larger deal – don’t be afraid to ask for pricing relief, especially if purchasing Advanced Security, Database Vault, or other options simultaneously.
• Assess Alternative Solutions: As mentioned, Oracle Label Security is one way to achieve row-level security; however, Oracle Database’s native VPD (Fine-Grained Access Control) can accomplish similar outcomes without incurring additional costs. The trade-off is that OLS provides a pre-built policy framework and integration (and possibly some performance optimization for this specific use). In contrast, VPD requires manual policy writing for each table. Depending on your team’s expertise, using VPD or even application-layer security logic might be viable for smaller-scale needs, saving the license cost. It’s worth comparing the implementation effort vs. the licensing fee to make a justified decision.
• Monitor and Audit Internally: Treat Oracle’s license auditing approach as a guide for internal audits. Use Oracle’s provided tools or third-party scripts to regularly check if OLS has been enabled anywhere in your environment. If an internal audit finds unapproved OLS usage, take action to either remove those features or procure licenses before Oracle’s official audit finds them. Early detection can turn a potentially costly surprise into a manageable budget item.
• Cloud as a Cost Lever: If you’re planning a move to cloud or already in Oracle Cloud, utilize the included options on higher-tier services to your advantage. In some cases, moving a workload that requires OLS to Oracle Cloud’s High Performance tier might be more cost-effective than licensing the option on-premises, especially for short-term projects or if you already intend to use that cloud service. Always conduct a cost comparison over your planned time horizon – comparing cloud subscriptions versus perpetual licenses and support – to determine which is more economical for the OLS use case.

By considering these strategies, enterprises can minimize the financial impact of Oracle Label Security licensing while still meeting their security requirements.

Recommendations

• Conduct a Feature Inventory: Proactively identify which Oracle Database features and options (like OLS) are enabled or in use across all your database instances. This inventory is the foundation for compliance and cost optimization.
• Educate and Govern Usage: Institute a governance process where DBAs and architects must get approval before implementing Oracle Label Security. Training staff on what features incur extra licensing prevents accidental use.
• Align Licensing with Database Metric: Always match Oracle Label Security licenses to your database license metric (processors or user count) and quantities. This ensures full coverage and avoids any licensing gaps.
• Consider Security Bundles: When possible, negotiate OLS as part of a larger security bundle (with Database Vault, Advanced Security, etc.) during Oracle contract discussions. Oracle may offer better discounts when multiple options are purchased together.
• Leverage Oracle Cloud if Feasible: If your strategy allows, deploy OLS-required workloads on Oracle Cloud service tiers that include the option. This shifts the cost to a predictable subscription and might reduce upfront spend.
• Review Periodically: Treat OLS licensing as a living aspect of your IT portfolio. Regularly review whether it’s still needed in each instance, and whether the usage justifies the ongoing cost (especially support renewals).
• Plan for Audits (No Fear): Prepare for Oracle audits by maintaining thorough documentation of where and why OLS is used, along with proof of licenses. A well-documented environment will make audits far less painful and show good faith in license management.
• Explore Alternatives for New Projects: For new applications requiring row-level security, evaluate whether built-in Oracle features or alternative database technologies can meet the requirements without additional licensing. Use OLS when it fits a requirement that can’t be easily met otherwise.

Checklist: 5 Actions to Take

1. Audit Your Databases Now: Run an internal check on all Oracle databases for any signs of Oracle Label Security (e.g., existence of LBACSYS schema, OLS policies, or labeled data). Document where it’s in use.
2. Verify Licensing Coverage: For each database identified in step 1, ensure that you have purchased OLS licenses sufficient for the number of processors or users. If not, decide whether to remove the feature or acquire the needed licenses.
3. Update Internal Policies: Revise your database administration guidelines to explicitly require a license impact assessment before enabling any optional feature, such as OLS. Communicate this policy to all relevant teams.
4. Engage with Oracle or Partners: If you anticipate needing OLS (e.g., due to a new compliance requirement), engage Oracle or a licensing expert early. Discuss bundling OLS into enterprise agreements or cloud migrations to find the most cost-effective path.
5. Monitor Continuously: Implement a periodic (e.g., quarterly) review of Oracle feature usage. Integrate this check into change management – if someone installs or enables OLS, your asset management team should be alerted to validate licensing immediately.

FAQ

• Q: Is Oracle Label Security included in Oracle Database Enterprise Edition by default?
  A: No. Oracle Label Security is a separate option for Oracle Database Enterprise Edition. You must purchase a license to use it on-premises (it’s only included with certain special editions or cloud service tiers, not the default EE license).
• Q: How is Oracle Label Security licensed – per user, per processor, or database?
  A: It can be licensed either by processor or by Named User Plus, depending on how your database is licensed. Essentially, you license OLS for the same metric and scope as your Oracle database. If your DB is processor-licensed, get the equivalent number of processor licenses for OLS on that server (all processors must be covered). If your DB is NUP-licensed, purchase OLS NUP licenses equal to at least the number of named users on that database (respecting Oracle’s per-processor user minimums).
• Q: What happens if we enable OLS without licensing it?
  A: Using OLS features without a proper license puts you out of compliance. If Oracle audits your company, their scripts will flag the usage of OLS (for example, any defined labels or policies). The outcome can be a demand to purchase licenses for the period of unlicensed use (potentially with back support fees and possibly penalties). It’s a costly risk. It’s best to avoid using the feature until licenses are in place or to immediately disable and remove any OLS configurations that were enabled accidentally.
• Q: Does having Oracle Database Vault mean we don’t need an OLS license?
  A: No – you still need an OLS license to create and use label security policies. Database Vault enables the OLS mechanism internally for Vault’s features, but that doesn’t entitle you to freely use OLS on your data. Unless OLS is separately licensed (or included via a cloud service), you cannot deploy your row labels and label-based access rules. Think of them as separate options: they complement each other, but each requires its license.
• Q: Can we use Oracle Label Security in a development or test environment without licensing?
  A: From a licensing standpoint, any non-production use still requires a license unless you are using an edition where it’s free (like Oracle Database Personal Edition or the free Oracle XE for strictly non-production purposes). Oracle does offer separate licenses for development and testing in certain contexts (for example, using Oracle’s Developer License or Application Testing Suite agreements). Still, generally if you’re installing Enterprise Edition with OLS in a dev/test environment that isn’t covered by special developer terms, you should have it licensed or use Personal Edition/XE for that purpose. Always clarify with Oracle or your license counsel before assuming you can use it in development or testing without cost.
